Thank you for filling out the survey. The results are shown below. If you have any questions, please contact AEi Systems.

More information is available about our Analysis Services and Support for Linear Technology models.

1. How do you evaluate end-of-life ("EOL") STABILITY performance for your linear regulator circuits?

a. We do not evaluate EOL Stability 0%
b. We ONLY TEST Beginning-of-life (BOL) Stability 54.2%
c. We use SPICE or another Analog Simulator 45.8%

2. If you test regulator stability, WHEN do you do it?

a. At the prototype stage 83.3%
b. Engineering Model stage 66.7%
c. Integrated System 12.5%

3. If you test regulator stability, HOW do you do it?

a. Transient Step Loading 87.5%
b. Bode Plots 75%
c. Non-invasively (Output Impedance) 20.8%
d. We generally don't 0%

4. Do you perform WCCA (worst case circuit analysis) on your linear regulators including stability, ripple rejection, step load, headroom, current limit, regulation, and startup?

a. No or rarely 12.5%
b. No, unless our customer requires us to perform the WCCA 0%
c. Yes but not all of the analyses mentioned 37.5%
d. Yes, most if not all of the analyses mentioned 50.0%

5. If you use SPICE to perform EOL regulator stability analysis do you:

a. Make your own regulator IC models 45.8%
b. Use LTxxx models to represent the RHxxx parts in your simulations (for example, use the LT1573 to model the RH1573) 58.3%
c. Tolerance the IC model itself (internal parameters like bandwidth, error amp gain, etc.) 50.0%
d. ONLY tolerance the parts external to the regulator 8.3%
e. Validate the IC model against Bench Test Data (as opposed to just the data sheet) 45.8%
f. Use "ladder models" (AVX Spitan/Kemet Spice) to model the capacitors 20.8%
g. Generally find "RLC" models acceptable for the capacitors 37.5%
h. Test the actual capacitor impedance/ESR and make your own "ladder" models? 29.2%

6. If/when you perform a Monte Carlo analysis,

How many cases do you normally run? cases
a. How many sigma (standard deviations) do you use to compute the performance range? Varies, 12-1000
b. We use the end points (worst simulation results to indicate the worst case performance). 73.3%

7. What test equipment do you use for stability (gain-phase) testing?
(Check all that apply)

a. Electronic load 54.2%
b. Ridley AP300 Network analyzer 20.8%
c. Venable Network Analyzer 25%
d. Agilent Network Analyzer 33.3%
e. Other Network Analyzer 20.8%

8. What is your job description?

a. Program Management 16.7%
b. Design Engineering 79.2%
c. Test Engineering 0%
d. Reliability Engineer 4.2%
e. Other 0%
